DIODE S/MINOR, 1700W, 1.5m
- Practical kit with DIODE S and MINOR
- Welding device with external blower
- Ideal for assembly work
Details Ideal combination
The popular hot air tool, DIODE S, in combination with the external MINOR from Leister is the ideal kit for various applications, thanks to its low weight and high performance. o They're connected to one another in a fixed manner and are ready for direct use. Thanks to the external blower, the hot air tool, DIODE S, has a narrow handle unlike other hot air tools, which allows it to fit well into the user's hand. DIODE S with MINOR is the ideal kit for various applications and job sites.
Technical Data
Voltage:120V 1700W (article: 101.447); 230V 1700W (article: 101.441)
Frequency:50/60 Hz
Temperature:20 - 600 °C / 68 - 1112 °F
Temperature Setting Stepless:Yes
Stepless Air Volume Adjustment:No
Static Pressure:5000 Pa / 0.72 psi
Eco-mode:No
Display:No
E-Drive:No
Outdoor Use:Yes
Nozzle Connection Ø:31.5 mm / 1.25 in
Length:256 mm / 10.07 in
Device Diameter:57 mm / 2.24 in
Handle Diamter:40 mm / 1.57 in
Power Cable Length:3 m / 9.84 ft
Air House Length:1.5 m / 4.92 ft
Plug:US, 2 poles, 15A, polarized (article: 101.447); EU, 2 poles, 16A (article: 101.441)
Noise Emission Level:67 dB (A)
Approvals:CB Certification; CE; UKCA
Protection Class:II
Hights: Perfect combination
1. Suitable for various applications
2. MINOR blower included
3. DIODE S with ergonomic handle
4. Practical kit with DIODE S and MINOR
5. Welding device with external blower
6. Ideal for assembly work
Application: Virtually unlimited
1. Aquaculture construction and repair
2. Boat construction and repair
3. Foundation waterproofing
4. Plastic repairs
5. Pipe and tube welding
6. Plastic tank fabrication
7. Cable shrinking
Article number | Item name | Voltage | Power | Nozzle connection ø | Air hose length | Plug |
101.441 | DIODE S/MINOR, 230V/1700W, 1.5m, EU plug | 230 V | 1700 W | 31.5 mm / 1.25 in | 1.5 m | EU, 2 poles, 16A |
101.447 | DIODE S/MINOR, 120V/1700W, US plug | 120 V | 1700 W | 31.5 mm / 1.25 in | 1.5 m | US, 2 poles, 15A, polarized |
101.449 | DIODE S/MINOR, 100V/1500W, JP plug | 100 V | 1500 W | 31.5 mm / 1.25 in | 1.5 m | JP, 2 poles, 15A |
136.241 | DIODE S/MINOR, 230V/1700W, CN plug | 230 V | 1700 W | 31.5 mm / 1.25 in | 1.5 m | CN, 2 poles, 10A |
