Gas Flow Rate: 100L/H
Max Water: 1.6L
Electrolyte Concentrations: 3%
Working Pressure: 0-0.16bar
Power Input: AC 110V / 220V
Packing Size: 330*330*440mm
Weight: 17.6lbs / 8kg
Configuration:
1. Large Digital Screen - intuitive operation
2. Timing function--accurately control the running time, free from supervision.
3. Hydrogen and oxygen cooling--Make water and gas more thoroughly separated.
4. 48V High-efficiency Electrolysis Tank--Electrolysis efficiency is increased by 30%, and electrolyte concentration is reduced from 20% to 7%.
5. 48V High-efficiency Electrolysis Power Supply - Designed for high-efficiency electrolysis tank.
Model number: F12
Hydrogen-oxygen flow rate: 2.2L/min
Maximum water volume: 1.6L
Electrolyte concentration: 3%
Operating pressure: 0-0.16 bar
Input voltage: AC 110V / 220V
Paking size: 330*330*440mm
Weight: 17.6lbs / 8 Kg
Configuration:
1. Digital large screen display - intuitive operation.
2. Water shortage alarm - protect the electrolyzer and prolong the life of the machine.
3. Large gas production
4. Pure gas
Model number: F13
Hydrogen-oxygen flow rate: 2.2L/min
Oxygenation flow rate: 1-4L/min
Maximum water volume: 1.6L
Electrolyte concentration: 3%
Working pressure: 0-0.03bar
Power input: AC 110V/220V
Package size: 33*33*44cm
Weight: 17.6lbs / 8KG
Configuration:
1. Digital large screen display - intuitive operation.
2. Water shortage alarm - protect the electrolyzer and prolong the life of the machine.
3. Timing function-accurately control the running time.
4. Oxygen boosting function--Increase the gas output of the machine, the increment is adjustable.
5. Post-filter-Recover the water in the system to make the gas pure.
6. Pre-filter-Improve the purity of gas, make the gas more pure.
Model number: F16
Medium: Pure Water
Maximum Water Volume: 1.6L
Maximum Electrolysis Voltage: 16V
Maximum Electrolysis Current: 26A
Maximum Hydrogen-Oxygen Gas Flow Rate: Hydrogen: 1.2 L/min; Oxygen: 0.6 L/min
Oxygen Flow Rate: 1-4L/min
Configurations:
1. Large Digital Screen —— make data visual and facilitate machine.
2. Water Shortage Alarm —— protects the electrolyzer and extend machine life.
3. Timer —— control the running time.
4. Oxygen Controller —— increase the amount of gas coming out of the machine and the increment is adjustable.
5. Post-filter —— recover the water in the system and make the gas purer.
6. Pre-filter —— improve the purity of the gas and make gas purer.
7. Condensate Water Alarm —— Protects the purity of hydrogen and oxygen gases.
Operating Pressure: 0-30kpa Applications:
Polishing uneven and hard-to-reach area of acrylic products and acrylic parts without any residue, such as acrylic sheets, signs and acrylic lettering
Welding metal wires, especially enameled copper wires in electric motors and transformers
Melting and fusing of silver, platinum, and their spots and face welding sealing small quartz glass bottles and ampules
Spot annealing of small parts in all metals
Welding, cutting and drilling of very thin metals
Welding copper tubes
1. Large Digital Screen —— make data visual and facilitate machine.
2. Water Shortage Alarm —— protects the electrolyzer and extend machine life.
3. Timer —— control the running time.
4. Oxygen Controller —— increase the amount of gas coming out of the machine and the increment is adjustable.
5. Post-filter —— recover the water in the system and make the gas purer.
6. Pre-filter —— improve the purity of the gas and make gas purer.
7. Condensate Water Alarm —— Protects the purity of hydrogen and oxygen gases.
Operating Pressure: 0-30kpa Applications:
Polishing uneven and hard-to-reach area of acrylic products and acrylic parts without any residue, such as acrylic sheets, signs and acrylic lettering
Welding metal wires, especially enameled copper wires in electric motors and transformers
Melting and fusing of silver, platinum, and their spots and face welding sealing small quartz glass bottles and ampules
Spot annealing of small parts in all metals
Welding, cutting and drilling of very thin metals
Welding copper tubes
